Pressure Transmitter BH-TP01 BH-2088
Bosean pressure transmitter is widely used in the process control field of industries such as petroleum, chemical, metallurgy, power, food, papermaking, medicine, machinery manufacturing, and scientific experiments. Our company has a wide range of product types, including pressure, differential pressure, hydraulic, temperature and other process monitoring instruments, which can meet the needs of customers in different scenarios. We provide pressure transmitter OEM/ODM service.
- Free calibration
- Lifetime maintenance
- 1-year warranty
Feature
- Adopting imported silicon piezoresistive sensors.
- Two wire current and three wire voltage output
- A variety of electrical connections are optional
- Good Resistance To Vibration And lmpact
- Small size and easy to install
Specifications
| Pressure type | gauge pressure, absolute pressure |
| Accuracy | ±0.5%FS;±0.25%FS;±0.2%FS;±0.1%FS |
| Range | -100kPa...0~ 500Pa...60MPa |
| Long term stability | ≤0.2%FS/year |
| Temperature drift | ≤0.02% FS/℃(with in the range of 0-70℃) |
| Error accuracy | ± 0.2% of the measuring range |
| Start time | 2 seconds without heating required |
| Sensor core | 316L |
| Isolation membrane | 316L(customizable with other materials) |
| Protection level | IP65 |
| Pressure overload | twice the upper range limit |
| Working temperature range | -20℃~85℃ |
| Storage temperature range | 0-100% relative humidity |
